1500VA UPS Battery Backup
by Belkin
Specifications
September 8, 2007
Belkin 1500VA UPS: Introduction
Belkin 1500VA UPS: What's In The Box
•
Belkin 1500VA UPS: A Closer Look
Using The Belkin 1500VA UPS
•
Belkin 1500VA UPS: Specifications
Belkin 1500VA UPS: Conclusion
1500VA UPS Battery Backup
Model Number
F6C1500-TW-RK
Number Of AC Inputs
8
INPUT
Capacity
1500VA / 835W
Voltage Range
88 - 140V
Frequency
60HZ (+/- 3HZ)
OUTPUT
Voltage
Simulated sine wave, 120vac +/- 10%
Frequency
60HZ (+/- 1HZ)
BATTERY
Backup Time
120mins
Typical Recharge Time
Up to 12 hours recover @ 85% capacity
ENVIRONMENT
Ambient Operation
0 - 85% humidity non-condensing
0 - 40°C
CONFORMANCE
Safety
UL / c-UL, FCC Class B
Surge
IEEE C62.41 Category A Standard
PHYSICAL
Dimensions
3.5" (W) x 15" (H) x 13.1" (D)
Net Weight
23.54 lbs
MSRP
$199.99
Package Contents
UPS Unit
Bulldog Plus Shutdown Software
USB Cable
Serial Cable
Phone Line Cable
(4) Tower Stand Base Pieces
