| Master Panel II by Vizo |
|
| What's In The Box / A Closer Look March 30, 2008 |
|
| Master Panel II: Introduction • Master Panel II: What's In The Box / A Closer Look Master Panel II: Specifications • Master Panel II: Conclusion
|
|
The Master Panel II The MP II differs entirely from the original Master Panel, and we can see a variety of new additions and features.
 The back of the MP II is where all your connections will be joined to your motherboard. This will (or should) free up a lot of wires coming out the back of your computer case.
 In The Box Below is what you find in the box of the Master Panel II. A driver CD for Windows 98 and Windows 98SE users is offered. Of course, you really shouldn't have Windows 98 of any version by now (should you?). The user manual gives a lot of nice illustrations to show you where the included wires connect to.
 Seen below are the audio and video cables for your internal hookup to your motherboard. Vizo has them labeled appropriately for even easier identification and convenience when connecting them to your mobo.
 IEEE 1394 (i.e., "Firewire") and USB 2.0 cables are included to hook up to your motherboard internally.
 Shown below are the power cables and eSATA cable for controlling up to two fans.
 VIZO provides a motherboard bracket, three cable ties, and screws for mounting.
|
|
